IK Multimedia

Z-TONE Buffer Boost

€139,00 incl. VAT
Checking availability...
Required fields:
    🐣 Easter Holiday Notice:
    You can place your order and lock in the deal now, but please note that order processing and shipping will begin on April 22nd.
    Payment options
    Deliveries are carried by
    Physical Stores In Riga and Rotterdam
    14 Day Money Back Guarantee
    Buy Now Pay Later options (in3, Klarna)
    DescriptionZ-TONE Buffer Boost

    Preamp/DI pedal with advanced tone shaping

    Guitar & bass pedalboards are all about exploring new tones & textures, creating a wide range of sound for your instrument. Z-TONE® Buffer Boost takes your live rig to a new level, letting you shape the sound of your instrument with the input circuits from our award-winning AXE I/O interface.

    Key Features

    • Active/Passive pickup selector
    • PURE channel for transparent sound
    • JFET channel adds warmth & harmonics
    • Z-TONE variable impedance control creates a wide range of tones
    • Buffers signal for longer pedalboards & cable runs
    • Boost circuit adds volume & drive
    • Alternate outs for mixers & PAs
    • Ground lift switch eliminates buzz & hum
    • Designed and made in Italy

    Z-TONE Buffer Boost Specifications

    Topology

    • Ultra low noise, high bandwidth and ultra low distortion preamp, buffer and direct box, with boost control and variable gain and input impedance.
    • Transformer-based galvanically isolated balanced output and electronically buffered low impedance unbalanced output.
    • PURE and JFET input stages for total transparency or added harmonics.

    Audio specs

    • I/O Gain: Unitary, from 1/4” input JACK to both 1/4” and XLR outputs when GAIN is at 0dB and Z-TONE at the SHARP position.
    • Gain Range: From -8dB to +8dB
    • Boost range: From 0dB to +10dB
    • Input impedance - Z-TONE set on PASSIVE mode: Variable from 1MΩ down to 2.2kΩ
    • Input impedance - Z-TONE set on ACTIVE mode: Approx 20kΩ
    • Output impedance, unbalanced out: 56Ω
    • Output impedance, balanced out: 600Ω
    • Max input level before clipping: +13dBm when powered by 48V phantom, +9dBm when powered by 9V battery
    • Dynamic Range: better than 114dB(A) for both outputs, input gain at 0dB
    • Total Harmonic Distortion, balanced output, 1kHz, +4dBm input: 0.0033% (PURE), 0.2% (JFET)
    • Total Harmonic Distortion, unbalanced output, 1kHz, +4dBm input: 0.00055% (PURE), 0.2% (JFET)
    • Frequency response: from 5Hz to 30kHz -1dB
    • Phase deviation: 0° +/-10° from 20Hz to 20kHz

    Power

    • Phantom power: +48V phantom on Balanced output
    • Battery power: 9V - not included
    • External DC power: 9VDC, positive outside - not included
    • Current consumption from P48 phantom power source: 6.5mA

    Dimensions

    • Size: 10.8cm/4.25" x 12cm/4.72" x 5.8cm/2.28"
    • Weight: 600g/21.2oz

    Package includes

    • Z-TONE Buffer Boost unit
