iRig Mic Video

The ultra-compact professional audio/MIDI interface for all your recording needs

Now record with any of your gear on the go, and monitor in real-time with any compatible device! That’s iRig Mic Video, the ultra-compact professional quality audio and MIDI in/out for your mobile recording life!

iRig Mic Video is the next generation of the iRig Mic — the first mobile interface for connecting all of your recording gear to your iPhone, iPad, Mac, PC, or Android device to record on the go.

iRig Mic Video is a pocket-sized full-featured audio and MIDI interface that gives you 24-bit/96kHz recording studio quality sound everywhere you go with a few additional essential features for mobile recording.

First, iRig Mic Video is designed to be “plug and play” easy to use with all of your gear — studio mics, vocal performance mics, guitars, basses, keyboards — whatever it is, iRig Mic Video can handle it.

Second, iRig Mic Video features a new 1/8" stereo headphone out with preamp and level control, making it compatible with even the most recent iOS devices. Plus, when used with the optional DC power supply, iRig Mic Video will charge your iPhone or iPad while in use for unlimited recording time. iRig Mic Video also features a new MIDI Out jack that gives you even more flexibility and control over your outboard MIDI gear.

Bottom line: iRig Mic Video is the most versatile and intuitive “all in one” mobile interface available.

Technical Specifications:

• Combination input XLR and 6.3 mm jack for microphone, line, and instrument signals
• High-quality preamplifier with adjustable gain
• High-quality ADDA conversion with up to 24 bit / 96 kHz
• Adjustable stereo headphone output
• MIDI input and output
• Power supply via USB, 2x AA batteries, or optional mains adapter (not included)
• Headphone output: 3.5 mm stereo jack unbalanced, 100 mW at 50 Ohm
• MIDI input and output: 2x 2.5 mm mono jack
• Power supply connection 5.4 V DC (optional power supply: Article no. 417705, not included)
• Device connection Mini-DIN
• Dimensions: 43 x 127 x 37 mm
• Weight: 120 g (without batteries)

Microphone input:

• XLR balanced
• +48V +/-4V Phantom powering
• 40 dB gain
• Impedance 1.6 kOhm
• Frequency range: 20-20000 Hz +/-1.5 dB
• Noise level -103 dB(A)
• -97 dB RMS

Instrument input:

• 6.3 mm jack, unbalanced
• 27 dB gain
• Impedance 1 MOhm
• Frequency range: 20-20000 Hz +/-1.5 dB
• Noise level -103 dB(A)
• -97 dB RMS

Includes:

• iRig Mic Video Audio MIDI Interface
• Lightning to Mini-DIN adapter cable 0.6 m
• USB to Mini-DIN adapter cable 0.6 m
• 2x 2.5 mm jack MIDI adapter cable 1.6 m
• 2x 1.5 V AA battery
• Comprehensive software package AmpliTube 4 and AmpliTube 5 SE as download via manufacturer/app store
